Product Series: Super Matte
Regular sizes: 1250*0.2
Thickness of the protective film: 0.06mm
With back coating: Yes
Product Colors:
Size, color and protective film can all be customized.
PET Solid Color Super Matte Decorative Film Manufactured using polyethylene terephthalate - 1,4-cyclohexanedimethanol (PETG) as the base material, precisely blended with color masterbatch and functional additives. The base film - cyclohexanedimethanol (PETG) as the base material. Precisely formulated color masterbatch and functional additives are blended to create the base film through cast extrusion. This film undergoes surface treatment using a 172nm nano-light excimer process under nitrogen protection, resulting in a new eco-friendly surface decorative material that combines ultra-matte, superior abrasion resistance, stain resistance, and anti-fingerprint properties. This series is branded as NCT Decorative Film in China.
1 Base film: The core material is PETG (polyethylene terephthalate glycol-1,4-cyclohexanedimethanol), a non-crystalline copolyester formed by the copolymerization of three monomers: terephthalic acid (PTA), ethylene glycol (EG), and 1,4-cyclohexanedimethanol (CHDM).
2 Coating: Utilizes a 172nm nanophotonic process with nitrogen-protected excimer treatment to impart core functional properties to the film surface.
3 Protective film: Features a 0.06mm-thick PE protective film for safeguarding purposes.
4 Back coating: A specialized functional coating applied to the film's reverse side, capable of elevating the dyne value to 38 or higher while enhancing adhesion strength.
930Y - Ⅱ S/H
909Y - Ⅱ S/H
947Y - Ⅱ S/H
787Y - Ⅱ S/H
859Y - Ⅱ S/H
786Y - Ⅱ S/H
836Y - Ⅱ S/H
739Y - Ⅱ S/H
789Y - Ⅱ S/H
738Y - Ⅱ S/H
788Y - Ⅱ S/H
008Y - Ⅱ S/H
309Y - Ⅱ S/H
616Y - Ⅱ S/H
517Y - Ⅱ S/H
407Y - Ⅱ S/H
WellP Solid Color Super Matte Decorative Film use formaldehyde free and environmentally friendly materials, which have passed the US FDA food contact certification, Swiss SGS certification, and multiple medical grade raw material certifications, ensuring non-toxic and harmless properties, meeting food grade safety standards, and can directly contact the human body. Its excellent antibacterial performance can effectively inhibit bacterial growth, providing a green and healthy guarantee for the home environment. In addition, the product is recyclable and reusable, reducing its impact on the environment and perfectly aligning with the concept of environmental development.
WellP Solid Color Super Matte Decorative Film have excellent durability, high impact resistance, outstanding wear and scratch resistance, as well as excellent corrosion resistance, oil resistance, and yellowing resistance. These features enable it to easily cope with various impacts, frictions, and environmental conditions in daily home use, facilitate cleaning, and effectively extend the product's service life, ensuring stable performance throughout long-term use.
WellP Solid Color Super Matte Decorative Film excel in color stability, accurately controlling color differences between different batches of products at extremely low levels, far exceeding industry standards. This excellent batch color difference stability ensures consistent color performance of the product during large-scale production, providing customers with precise and long-lasting visual experience.
WellP Solid Color Super Matte Decorative Film applies advanced anti-fingerprint coating technology that significantly reduces visible smudges, grease marks, and handprints. Its ultra-matte, soft-touch surface keeps furniture looking clean and elegant with minimal maintenance, making it ideal for high-touch areas such as cabinets, wardrobes, doors, and wall panels. This performance ensures long-lasting visual clarity and a consistently refined appearance in daily use.
WellP Solid Color Super Matte Decorative Film are endowed with nano level delicate wrinkles on their surface through nano light processing technology, and achieve extremely low matte visual effects through unique diffuse reflection principles. This ultra matte finish not only presents a low-key and rustic texture, but also brings a high-end and understated aesthetic experience, endowing the product with unique artistic charm.
WellP Solid Color Super Matte Decorative Film provide two distinct yet equally excellent tactile experiences in terms of texture presentation: sanding and sliding. When you choose a sandy texture and lightly touch it with your fingertips, you can feel the delicate sand like texture, with every stroke carrying just the right amount of lag; The smooth texture is like gently stroking silk, and wherever the fingers go, it is silky smooth and silky, with a skin friendly and smooth touch that is pleasant. Two texture options meet the needs of different aesthetics and usage scenarios.
| NO. | Inspection Item | Test Method/Basis | Judgment Standard | Inspection Equipment | |
| 1 | Product Size | Width | Slices width ±2.0mm, roll width ±2.0mm. | Tape measure | |
| Thickness | ±0.02 | Measure the position of 12 points evenly in the width direction | |||
| 2 | Surface Effect |
Feel | Visual inspection, observe from different angles | Sand feel: obvious sand feel on the surface, | Feel |
| Smooth feel: delicate surface texture, silky smooth feel. | |||||
| Raised grain texture | Uniform texture, consistent texture size. | High power microscope | |||
| 3 | Protective film | Visual inspection | No residual glue, no scratches, damage, wrinkles, blistering, film lifting, oil residue debris pollution, etc., and the edges are trimmed neatly. | Visual inspection | |
| 4 | Color difference | GB/T 17657-2022 in 4.34 | Visually consistent, no obvious difference, compared to the surface standard sample △E ≤0.5, color difference between batches E≤0.3. | Visual inspection, color difference meter | |
| 5 | Hardness | GB/T 17657-2022 in 4.58 | Hardness ≥H, | Electric pencil hardness tester/weight | |
| 500g weight, Mitsubishi pencil 45° scratch, Note: Sample from the upper end at 100mm, take one sample each from the left, middle and right for testing, test 5 times for each sample, and it is qualified if no less than 4 times without scratches/scratches. | |||||
| 6 | Wear resistance | ASTM F2496 ISO 1518-1 ISO 1518-2 GME 60248 D42 1775 |
≥10r The coating surface is under 750g/cm2 pressure, slight pinpoint scratches or no scratches on the friction position after 10 cycles. |
Reciprocating wear testing machine/#0000 steel wool | |
| 7 | Scratch resistance | GB/T 17657-2022 in 4.42 | 1.2N (60g), | Scratch resistance tester | |
| ① No continuous scratches on more than 90% of the sample surface, | |||||
| ② Coating thickness ≤10um, | |||||
| ③ Front and back, horizontal, vertical and roll directions on a 3-inch core, no cracking is OK | |||||
| 8 | Gloss | Sand feel | GB/T 9754-2007 | White/Bright color series: | Gloss meter |
| 20° ≤1.5, 60° ≤4.5, 85° ≤10 | |||||
| Other colors: 20° ≤1.0, 60° ≤3.0, 85° ≤10 | |||||
| Smooth feel | White/Bright color series: | ||||
| 20° ≤1.5, 60° ≤4.5, 85° ≤12 | |||||
| Other colors: 20° ≤1.0, 60° ≤3.0, 85° ≤12 | |||||
| 9 | Stain resistance | Sand feel | GB/T 17657-2022 in 4.43 | ① No obvious discoloration after stain resistance test after 10 hours, | Huangyu liquid shoe polish, Nestle coffee 80℃ water, soy sauce, acetone, cola, aged vinegar, red ink, 6824 oily pen, 75% alcohol, nano sponge magic eraser |
| ② No obvious discoloration after acetone test after 30 minutes, | |||||
| ③ Red ink is wiped with clean water, | |||||
| ④ 6824 oily pen can be wiped off with 75% alcohol, | |||||
| ⑤ 6824 oily pen can be wiped clean with a nano sponge magic eraser when dry, | |||||
| ⑥ Oil stains/sweat oil on the head/cooking oil can be wiped off with alcohol/detergent, | |||||
| ⑦ Ordinary sweat marks/sweat fingerprints on hands can be wiped off dry or disappear naturally. | |||||
| Smooth feel | ① No obvious discoloration after stain resistance test after 10 hours, | ||||
| ② No obvious discoloration after acetone test after 30 minutes, | |||||
| ③ Red ink is wiped with clean water, | |||||
| ④ 6824 oily pen can be wiped off with 75% alcohol, | |||||
| ⑤ 6824 oily pen can be wiped clean with a nano sponge magic eraser when dry, | |||||
| ⑥ Oil stains/sweat oil on the head/cooking oil can be wiped off with alcohol/detergent. | |||||
| 10 | Water contact angle | GB/T 30693-2014 | Test water with 3 microliters of water, contact angle ≥70°. | Water contact angle tester | |
| 11 | Adhesion | Conventional | GB/T 17657-2022 in 4.57 | ≥4B, 3 times each for left, middle and right grid tests. | 3M#600/681 (replacement 610) test tape/grid cutter, water bath |
| Water boiling | ≥4B, 80℃/30 minutes, natural cooling ≥10 minutes, no cracking | ||||
| 12 | Yellowing resistance | GB/T 23983-2009 | △E≤3 | UV yellowing resistance test chamber | |
| (168hUVA340) | GB/T 17657-2022 in 4.32 | (Surface oil: △E≤0.7) | |||
| 13 | Light fastness | GT/T 17657-2022 in 4.31 | ≥3 grade | Xenon arc lamp test box, 8-level blue wool standard sample, gray sample card | |
| 14 | Winding | Packaging operation specification | 1250mm×3 inch compression-resistant foam tube or polished tube, smooth surface, no unevenness, neat winding, no edge running, 250 meters/roll, protective film facing outwards. | ||
| 15 | Product packaging | Packaging operation specification | The tape is dark brown tape. After processing, first wrap it with stretch film, and the outer packaging is packaged with pearl foam packaging paper printed with LOGO. Both ends of the product are sealed and packaged with paper corner protectors and hardened corner protectors. The packaging should be complete and undamaged. | Visual inspection | |
| 16 | Product identification Sample |
Visual inspection | ① Paste one large label (58mm*218mm, 3 in total) with the same information on the upper right corner of the outer packaging paper logo, flush with the bottom of the corner protector, in the middle of the top, and in the center of the back of the A4 sample (210mm*297mm). The identification is standardized, the content is comprehensive, clear, and correct. | Visual inspection | |
| ② The content on the label should include: product name, product series, protective film name, product item number, product specifications, product quantity, base material number, surface treatment number, production date and other information. | |||||
| Standardized identification, comprehensive, clear, and correct content, consistent with the order content | |||||
*For specific performance data and parameters, please download them from the Resource Center.
The product packaging adopts carefully designed outer packaging combined with protective film,The overall visual clarity is clear and can effectively protect the product,More helpful for customers to quickly identify the brand and strengthen their brand impression.
1 Flat Lamination Process: Flat lamination applies decorative film onto flat boards using PUR or hot-melt adhesive. This process delivers a smooth, seamless surface with excellent durability and a premium look. It is ideal for PET and PP films, providing superior scratch resistance, heat stability, and long-lasting color.
2 Wrapping Process: Wrapping uses PUR glue to cover decorative films on profiles such as edge bandings, moldings, and skirting boards. PET and PP films offer higher durability and color consistency, ensuring a perfect match with laminated panels.
Special Note: Wrapping Process requires customized specifications and coating formulations.
3 Vacuum Forming Process: Vacuum forming shapes heated decorative film over 3D surfaces using vacuum pressure. It's widely used for routed MDF doors and complex profiles. While traditionally applied with PVC films, the market is now shifting toward more eco-friendly alternatives.
Special Note: Vacuum Forming Process requires customized specifications and coating formulations.
1 Living Room Space
2 Bedroom Space
3 Dining & Kitchen Space
